POCKETCORDER SK-50P - Specifications

Specifications

Operation Type :	Galvanometric recorder
Input :	Standard 100 mV with temperature compensation 1, 2, 5, 10, 20, 4 - 20 mA Substandard 0 - 1 V to 0 - 50 V
Recording Type :	Pressure sensitive dotting
Dotting Interval :	60 sec. (25.4 mm/h)
Recording Paper :	Effective width 50 mm, Pressure Sensitive, Drooping Type 19 m, Spooling Type 9.5 m
Chart Speed :	Single Speed 25.4 mm/h (standard)
Accuracy of Meter Indicator:	±1.5% F.S. at 23 °C, w/out adaptor ±2.5% F.S. at 23 °C, w/adaptor
Power Consumption :	about 3.5 VA w/out adaptor, about 4.0 VA w/adaptor
Voltage & Frequency :	as specified by customers
Operating Temperature and Humidity Limits :	0 - 40 °C, 30 - 85% RH
Impedance :	100 mV approx. 50 ohms 1 mA approx.160 ohms 2 mA approx.43 ohms 5 mA approx.14 ohms 10 mA approx.4 ohms 20 mA approx.2 ohms 4 - 20 mA approx.2 ohms
Dimensions :	96 W× 96H × 155D mm 96W × 96H× 194D mm w/adaptor
Panel Cutting :	92 × 92 mm
Option :	An adaptor at the rear body for the following input
	* Thermocouple input K ( 300 °C range or over), T, J, R, E * Resistance temperature sensor input Pt 100 ohms (50 °C range or over, line resistance under 2 ohm line) * DC voltage input 10 mV oe over and below 100 mV

Model Notations

Please specify your requirements of A to E shown as the following in ordering.

SK-50P A B C D E

A (Chart Paper Type)
1	Drooping Type
2	Spooling Type
Z1	Special
B (Input)
1	DC 100 mV
2	DC 1 mV
3	DC 2 mV
4	DC 5 mV
5	DC 10 mV
6	DC 20 mV
7	DC 4 - 20 mV
Kxx	TC(K) K01: 0 - 300 °C, K02: 0 - 400 °C, K04: 0 - 600 °C, K05: 0 - 800 °C, K07: 0 - 1,200 °C
Txx	TC(T) T03: -50 - 50 °C, T04: -100 - 50 °C, T10: -50 - 150 °C, T17: -200 - 100 °C
Jxx	TC(J) J01: 0 - 300 °C, J07: 0 - 200 °C
Exx	TC(E) E07: 0 - 200 °C
Rxx	TC(R) R03: 0 - 1,600 °C
Ptxx	Pt100 ohms Pt01: 0 - 50 °C, Pt02: 0 - 100 °C, Pt03: 0 - 150 °C, Pt04: 0 - 200 °C, Pt07: -20 - 80 °C, Pt10: -50 - 50 °C, Pt11: -50 - 100 °C, Pt13: -100 - 50 °C Pt41: -50 - 0 °C, Pt52: 0 - 60 °C
V	DC 10 mV
Z2	Special
C (Power Supply)
1	100, 110, 115, 120 V, 50 Hz  NB1
2	100, 100, 115, 120 V, 60 Hz  NB1
3	200, 220, 230, 240 V, 50 Hz  NB1
4	200, 220, 230, 240 V, 60 Hz  NB1
Z3	Special
D (Chart Speed)
1	Single Speed
E (Option)
0	w/out addional function
1	10 mV input (with adaptor for rear body)
2	Pt 100 Ohms input (with adaptor for rear body)
3	Thermocouple input (with adaptor for rear body)
Z5	Special

NB1  Please specify the requested voltage when ordering.
NB2  Please specify the required scale when ordering.
