| Main filter element |
Sub filter element |
Size (mm) |
Application |
| Pore size(µm) |
Material |
Pore size(µm) |
Material |
Holder OD |
Element dia. |
Bottle |
Solvent |
| 2, 3, 5, 10 |
SUS316 |
20, 40 |
SUS316 |
φ15 |
φ11 |
500 mL |
Organic |
| φ25 |
φ20 |
3,000 mL |
| 4, 8 |
PTFE |
200 |
Carbon fiber |
φ15 |
φ11 |
500 mL |
None-organic |
| φ25 |
φ20 |
3,000 mL |
|
Combinations of main filter element and sub filter element pore sizes:
|
|
Main filter element pore size |
Sub filter element pore size |
Element material |
| (1) |
2µm 3µm |
20µm |
SUS316 |
| (2) |
5µm 10µm |
40µm |
SUS316 |
| (3) |
4µm 8µm |
200µm |
Carbon fiber |
|
 |
|
Contact us for combinations other than the above.
|
| Size(mm) |
For 500 mL bottle |
For 3,000 mL bottle |
| A |
φ15 mm |
φ25 mm |
| B |
6 mm |
9 mm |
|
 |
Cartridge type solvent filter structure:
|
 |
| No |
Description |
For 500 mL bottle |
For 3,000 mL bottle |
| Size(mm) |
| ① |
Nut |
φ15×6 (w/o threads) |
φ25×6 (w/o threads) |
| ② |
Spacer, PTFE |
φ11 |
φ20 |
| ③ |
Main filter element |
φ11 |
φ20 |
| ④ |
Sub filter element |
φ11 |
φ20 |
| ⑤ |
Holder |
φ15 |
φ25 |
|
